Demo 6.3: Clocks and the Binary Count Sequence

The previous demonstration took a JK flip-flop apart. This one puts the lid back on and asks what you can build with it, and the answer turns out to rest on a single observation about how we write numbers down.

Write the numbers 0 to 15 in binary, one per line. Then stop reading across the rows, which is the natural thing to do, and read down the columns instead.

   0000        Every column is a square wave.
   0001
   0010        The rightmost alternates every line.
   0011        The next alternates every two lines.
   0100        The next every four. The next every eight.
   0101
   0110        Each column is exactly half the
   0111        frequency of the one to its right.
   1000
   ...

Kuphaldt puts it plainly: “the LSB will oscillate at the highest frequency, followed by the next bit at one-half the LSB’s frequency, and the next bit at one-half the frequency of the bit before it.”

That is not a quirk of notation. It is the design of every binary counter ever built, because if the bits of a count are square waves at halving frequencies, then a device that halves a frequency is a device that counts. And you already have one: a JK flip-flop with both inputs tied high toggles once per clock edge, which is a division by two.

The other half of this demonstration is the horizontal axis. Everything here is drawn against t, with a clock frequency you choose, because a clock period is not a column on a diagram. It is a length of time, and at a gigahertz it is a nanosecond, which is about as long as light takes to cross a ruler.

How to use it

The binary count sequence puts the table and the four waveforms side by side and steps a cursor through them. The horizontal axis switches between clock periods and real time at whatever frequency you set, and the tables underneath give every bit’s frequency and period at that setting.

The JK as a black box is the device with its insides hidden. Set J and K, then click the clock and watch which of its two transitions it actually notices. The rising-edge and falling-edge symbols sit side by side so you can see that the difference between them is one bubble.

Dividing the clock by two ties J and K high and shows the result against the clock, with the frequency readouts following whatever you set on the first tab.

Clocks and the Binary Count Sequence

Why the columns of a binary count are square waves at halving frequencies, what a clock period is as a length of time, and the one flip-flop that halves a frequency.

derekmolloy.ie

The binary count sequenceThe JK as a black boxDividing the clock by two

Write out the count, then read down the columns instead of across the rows.

• A four-bit unsigned count runs 0000 to 1111, which is 0 to 15, and then starts again.
• Read across a row and you have a number. Read down a column and you have a square wave.
• The least significant column alternates every count, so it is a square wave at half the clock frequency. The next alternates every two counts, at a quarter. Then an eighth, then a sixteenth.
• Every column is exactly half the frequency of the one above it, all the way up.
• That is not a coincidence about how we write numbers. It is the design of every binary counter, because a device that halves a frequency is a device that counts.
• Everything below is drawn against time, and you can set the clock frequency to whatever you like. That second axis is the other half of this demonstration.

The clock1.000 GHz

1 Hz1 kHz1 MHz1 GHz

1 Hz32.768 kHz1 MHz16 MHz1 GHz2.4 GHz

One clock period

1.000 ns

T = 1/f = 1/1.000 GHz

In that time, light travels

30.0 cm

about the length of your forearm

A signal in copper manages

19.8 cm

roughly two thirds of light speed on a board

1 GHz: a Raspberry Pi 2 or 3.

The horizontal axis

Clock periodsTime at 1.000 GHz

PlayStep one clockRewind

Animation speed1.50 clocks/s

t = 0.00 of 16 clock periods

The amber marks are the clock's falling edges, which is where the count advances. The number between each pair of them is the count in force during that period, and the red line is where the animation has got to.

The count sequenceQ₃Q₂Q₁Q₀

n	binary	t from
0	0000	0 T
1	0001	1 T
2	0010	2 T
3	0011	3 T
4	0100	4 T
5	0101	5 T
6	0110	6 T
7	0111	7 T
8	1000	8 T
9	1001	9 T
10	1010	10 T
11	1011	11 T
12	1100	12 T
13	1101	13 T
14	1110	14 T
15	1111	15 T

Every bit's frequency at 1.000 GHz

bit	divides by	frequency	period
Q0 (LSB)	2	500.0 MHz	2.000 ns
Q1	4	250.0 MHz	4.000 ns
Q2	8	125.0 MHz	8.000 ns
Q3 (MSB)	16	62.5 MHz	16.0 ns
whole cycle	16	62.5 MHz	16.0 ns

Sixteen counts take 16.0 ns, so this counter gets back to zero 62.5 MHz times a second.

The animation is not running at that frequency

• The transport is set to 1.50 clock periods per second, because a human has to be able to see it.
• The frequency you have chosen is 1.000 GHz, which is 6.7e+8 times faster.
• So this is a slowed film. The shapes are right and the timescale is not, which is true of every timing diagram you will ever be shown.
• The numbers in the tables are the real ones. Only the red cursor is slow.

What 1.000 GHz actually means

• One clock period is 1.000 ns. That is the entire budget for everything the machine does between one tick and the next.
• In that time light travels 30.0 cm, and a signal on a circuit board manages about 19.8 cm.
• So at this speed the size of the board matters. A signal crossing a few centimetres of copper spends a real fraction of a clock period simply travelling, and no amount of clever design makes it faster.
• This is also why fast processors are physically small and why their clock is distributed with such care: parts of the chip would otherwise disagree about what time it is.
• None of this changes the shapes above. The same sixteen-count sequence happens either way, and only the axis changes.

Reading the picture both ways

• Down a column of the table is across a row of the waveforms. They are the same data in two arrangements.
• The table is the better one for answering "what is the count at step 11".
• The waveforms are the better one for answering "what does this bit look like on an oscilloscope".
• You will be asked both, and the second one is what you would actually measure on a bench.
• Notice that Q₀ changes at every falling edge, Q₁ at every second one, Q₂ at every fourth and Q₃ at every eighth.
• Notice also when each bit changes: only ever when all the bits below it are going from 1 back to 0. That observation is what builds the counter.

Why this is worth the fuss

• A clock is not a power supply and it is not a start button. It is a shared opinion about when "now" is.
• Every flip-flop in a machine looks at its inputs at the same instant, does one thing, and then waits. Between edges, nothing happens at all.
• That is what makes a large circuit predictable: instead of signals arriving whenever they please, everything happens in step.
• The price is that the slowest path in the whole design sets the clock period, and therefore the speed of the machine.
• Which is why a processor is quoted in gigahertz, and why that number alone tells you rather less than the advertising suggests.

Walkthrough

Step 1: Watch the columns, not the rows

Open The binary count sequence and press play, or step through it one clock at a time.

Follow Q₀ first. It changes at every falling edge of the clock: 0, 1, 0, 1, all the way along. Two clock periods make one complete cycle of Q₀, so Q₀ is a square wave at half the clock frequency.

Now follow Q₁. It changes half as often, so its period is four clock periods and its frequency is a quarter of the clock. Q₂ is an eighth. Q₃, the most significant bit, changes just twice in the whole sequence, giving one cycle in sixteen clock periods.

Read the frequency table on the right and check those against the numbers. Then look at the highlighted row of the count table and confirm it agrees with the waveforms at the cursor.

The observation that builds the counter

Look at when each bit changes rather than how often. A bit flips only when every bit below it is going from 1 back to 0.

Q₁ changes when Q₀ falls from 1 to 0. Q₂ changes when Q₁ falls. Q₃ changes when Q₂ falls.

That single sentence is the asynchronous counter, and you will build it from exactly that observation in the next demonstration.

Step 2: Put a real timescale on it

Press Time at 1 GHz and watch the axis labels change while the waveforms stay exactly where they are. It is the same picture; only the units moved.

Now drag the frequency slider around, and read the two figures under the clock panel:

• At 1 Hz, one period is a second and light travels 299,792 km in it, most of the way to the Moon.
• At 32.768 kHz, a watch crystal, one period is 30.5 µs and light gets 9 km, across a city.
• At 16 MHz, an Arduino Uno, one period is 62.5 ns and light gets 19 m, the width of a lecture theatre.
• At 1 GHz, a Raspberry Pi 2 or 3, one period is 1 ns and light gets 30 cm.

That last one is the one to sit with. In one clock period of a 1 GHz machine, light crosses about the length of your forearm, and a signal in copper on a circuit board manages only about two thirds of that, so 20 cm.

A Raspberry Pi is roughly 8 cm across. A signal getting from one side of it to the other therefore spends something like half a clock period simply in transit, before it has done anything useful. Nothing about the design can make that faster; it is the speed of light and the size of the board.

This is why fast computers are physically small, why a processor die is a few millimetres across, and why distributing a clock across a large chip so that every corner agrees about when “now” is turns out to be one of the harder problems in the field.

The animation is a slowed film

The transport runs at a couple of clock periods per second so that a human can watch it. The frequency readout is a separate matter entirely.

At 1 GHz the real circuit is running roughly a billion times faster than the picture. The shapes are right and the timescale is not, which is true of every timing diagram you will ever be shown, including the ones in data sheets.

Step 3: Meet the black box

Open The JK as a black box.

There are no gates here any more. There is a rectangle with three inputs and two outputs, and two pieces of notation that carry all the meaning:

• The small triangle against the clock input is the dynamic input indicator. It says this input responds to an edge, not to a level. A latch has no triangle; that is how you tell the two apart on a schematic.
• A bubble on the outside of the boundary means active low. On the clock input it moves the action from the rising edge to the falling one.

Set J = 1 and K = 1, then click the clock button twice and watch what happens. One of those two clicks flips the output and the other does nothing at all, because a falling-edge device sees exactly one instant per clock cycle and ignores the rest of it.

Now switch to Rising edge and do it again. The device is now triggered by the other click. Compare the two symbols in the panel beside it: same box, same triangle, and one has a bubble.

Step 4: Work through the state table

Try each row of the table in turn, clicking the clock after each change:

J	K	What happens at the active edge
0	0	Hold. The output keeps whatever it had.
0	1	Reset. The output is forced to 0.
1	0	Set. The output is forced to 1.
1	1	Toggle. The output changes to the opposite of what it was.

Then change J or K without clicking the clock, and notice the output does not move. J and K are not commands, they are an instruction about what to do at the next active edge. That separation is the entire reason for having a clock: the inputs are free to settle while nothing is listening.

The row that matters for everything after this is the last one. Hold, set and reset are all things a plain latch could do. Toggle is the one that needs the feedback, because the output depends on its own previous value, and that is what makes the circuit sequential rather than combinational.

Finally, press Pulse CLR low. The output goes to 0 immediately, with no clock edge involved at all. That is what asynchronous means, and it is how a counter is reset to zero without having to clock through the rest of the sequence. Note the bubble on that input too: it is active low, so an unused clear is tied high, which is the pull-up resistor demonstration turning up again in a new context.

Step 5: Turn a toggle into a divider

Open Dividing the clock by two.

J and K are now strapped permanently to logic 1, so the only row of the state table available is toggle. Every active edge, the output flips. That is the whole circuit.

Count the edges and the arithmetic is forced:

1. There is exactly one active edge per clock period.
2. There is exactly one output transition per active edge.
3. Every complete cycle of a square wave contains two transitions, one up and one down.
4. So one output cycle needs two active edges, which is two input periods. Divide by exactly two.

Not approximately two, and not two on average. It is a matter of counting rather than of measurement, and nothing about it depends on the shape of the clock, how long it stays high, or the frequency.

There is a useful side effect worth noticing: the output comes out with a clean 50% duty cycle even if the input was lopsided, because the output only knows about edges and not about what happened between them. Dividers are sometimes put into a circuit for that reason alone.

Step 6: Close the loop

Now compare the Q waveform on this tab with the Q₀ waveform on the first tab.

They are the same waveform. Not similar, identical: one flip-flop in toggle mode produces exactly the least significant bit of a binary count.

Which raises the obvious question. If one of these gives you the first column, what gives you the second? Q₁ is half the frequency of Q₀, and you have a device that halves frequencies, so feed Q₀ into another one. Then a third, and a fourth.

Four flip-flops in a chain, each clocking the next, and the four outputs are the four columns of the count table. That is a counter, and it is the next demonstration.

Fifteen of these are on somebody’s wrist

Set the clock to 32.768 kHz and ask why a watch crystal is that odd number.

It is 2¹⁵. Divide it by two fifteen times over and you have exactly one cycle per second, which is the second hand. No arithmetic, no software, no calibration: fifteen copies of the circuit on this tab, in a row.

That is also why the crystal is that frequency rather than a rounder one. A power of two is what divides cleanly all the way down to one.

Check your understanding

Quiz

Select 0/1

In a four-bit binary count driven by a 1 GHz clock, what is the frequency of the most significant bit Q₃?

derekmolloy.ie

Quiz

Select 0/1

A JK flip-flop symbol has a triangle against its clock input and a bubble on the outside of that same input. What does that combination mean?

derekmolloy.ie

Quiz

Select 0/1

Why does a JK flip-flop with both inputs tied high divide its clock frequency by exactly two, rather than approximately two?

derekmolloy.ie

Concept Match

Match each item to what it is

derekmolloy.ie

Quiz

Select 0/4

Which of these are true of a clocked flip-flop between one active clock edge and the next? Select all that apply.

derekmolloy.ie

Wrap-up

Five things to take away.

1. The columns of a binary count are square waves at halving frequencies. The LSB runs at half the clock, the next at a quarter, the next at an eighth. Read down the columns rather than across the rows and this is impossible to miss.
2. A bit changes only when every bit below it goes from 1 back to 0. That observation is the counter, and the next demonstration builds it from exactly that sentence.
3. The triangle means edge triggered and the bubble means the falling edge. Two marks, two independent facts, and misreading the bubble halves the number of edges you thought you had.
4. Toggle mode divides by exactly two, by a counting argument that has nothing to do with time, duty cycle or frequency. One toggling flip-flop produces precisely the least significant bit of a binary count.
5. A clock period is a length of time. One nanosecond at a gigahertz, in which light travels about 30 cm and a signal on a board about 20. That is the real reason fast computers are small.

What comes next is the obvious construction. If one divider gives you the first column of the count, chain four of them and you have all four, which is an asynchronous or ripple counter. It works, and it has a fault: each flip-flop’s output arrives a propagation delay after its clock, so in a chain those delays accumulate, and for a few tens of nanoseconds the four outputs show a count that was never supposed to exist. The synchronous counter fixes it by clocking every stage from the same signal and using gates to decide which stages should toggle. Both have demonstrations of their own, and both start from the two ideas on this page.
